An ambulance is a vehicle for transportation of sick or injured people to, from or between places of treatment for an illness or injury, and in some instances will also provide out of hospital medical care to the patient. The word is often associated with road going emergency ambulances which form part of an emergency medical service, administering emergency care to those with acute medical problems.
Specification
Specification of FOTON Ambulance | |||
| Item | Specification | Item | Specification |
| General | |||
| Truck Name | Ambulance | Overall Dimension (mm) | 5380×1920×2505 |
| Truck Brand | FOTON | Gross / Curb Weight (kg) | 3400 / 2060 |
| Truck Model | * | Approach / Departure Angle (°) | 16 / 17 |
| Max. Speed (km/h) | 145 | Front / Rear Overhang (mm) | 1190 / 1080 |
| Chassis | |||
| Chassis Brand | FOTON | Chassis Model | * |
| Wheel Base (mm) | 3100 | Leaf Spring | -/3+1 |
| Traction System | 4 x 2 | Quantity of Axles | 2 |
| Rated Passenger | 5~8 | Front / Rear Axle Load (kg) | 1630/1770 |
| Transmission | 5 speed, manual | Front / Rear Wheel Tread (mm) | 1655 / 1650 |
| Tyre Model | 195R15C | Quantity of Tyre | 4 |
| Engine (Motor) | |||
| Brand | FOTON | Type of Fuel | Diesel |
| Model | ISF2.8s4129P | Displacement (ml) | 2780 |
| Max. Power (Hp) | 130 | Emission Standard | Euro 5 |
| Standard Configuration | |||
| 1) Control plate of siren and alarm lamp mounted in driver's cab | 1 set | ||
| 2) Adjustable volume alarm apparatus | 1 set | ||
| 3) Red flashing alarm light bar 100w mounted on the front roof of vehicle and with 3 pieces lights | 4 pcs | ||
| 4) Red flashing alarm lamps four sides of vehicle outside roof | 10 pcs | ||
| 5) Composite material interior decoration in patient compartment | 1 set | ||
| 6) Medicine cabinet | 1 set | ||
| 7) Oxygen cylinders 10L | 1 pc | ||
| 8) Ultraviolet radiation disinfector light | 1 pc | ||
| 9) Dirt bucket | 1 pc | ||
| 10) Individual seat | 3 pcs | ||
| 11) Long bench one piece (suitable for 3 people) with safe belts, mounted in right side of patient's compartment | 1 pc | ||
| 12) A foldable doctor seat (with safe belt) mounted to floor near to compartment wall | 1 pc | ||
| 13) Partition wall between driver's cab and patient's compartment, a glass window in wall to make observation | 1 set | ||
| 14) 12V light lamp | 2 pcs | ||
| 15) Intelligent inverted power supply system (12-220V) 500W | 1 set | ||
| 16) 220V wall outlet | 1 set | ||
| 17) Interior medical floor | 1 set | ||
| 18) Cross mark outside marking | 1 set | ||
| 19) The original air conditioning is installed in driver's cab and in patient's compartment | 2 sets | ||
| 20) Exhaust system is installed on patient's compartment roof | 1 set | ||
| 21) Multi-functional interior roof in patient's compartment, with handrail, transfusion hanging bracket | 1 set | ||
| 22) Portable and foldable stretcher | 1 set | ||
| 23) Automatic loading-and-unloading stretcher | 1 pc | ||
| 24) Hand-free intercom system between driver's cab and patient's compartment | 1 pc | ||
| 25) 100W loud speaker | 1 pc | ||
| 26) Oxygen reducing valve | 1 set | ||
| 27) Fire extinguisher | 1 set | ||
| NOTE: | |||
| 1. Any part can be customized depending on customers' demand. | |||
| 2. 12 months whole vehicle warranty | |||
| 3. We could support you original spare parts. Besides, we can give assistance in the following days by email or telephone. If necessary, our outwork engineer could go for technical assistance. | |||
| 4. MOQ: 1 unit | |||
